ST 30, RHP, Self Lube® Take-up bearing unit
Metric, Bearing unit, Cast iron, Set screw locking
$38.28
In stock
Metric, Bearing unit, Cast iron, Seal and flinger on both sides, Set screw locking, EAN code: 07316570121117
| Brand | SKF |
|---|---|
| Mfr Part No. | TU 30TF |
| Acorn Code | TU30TF-SKF |
| HS Code | 8483 20 00 00 |
| COO | Italy (IT) |
Take-up ball bearing units, consisting of an insert bearing based on a sealed deep groove ball bearing mounted in a grey cast iron housing. Typically mounted in take-up frames, the unit has an inner ring extended on both sides and is locked by tightening a set screw on the inner ring, which makes it easy to mount.
• Designed for an alternating rotation
• Quick and easy to mount onto the shaft
• Accommodate static initial misalignment
• Long service life
• Reduced noise and vibration levels
| Manufacturer Product Code | TU 30TF |
|---|---|
| Basic Product Description | Y Bearing Take-up bearing unit |
| Measurement | Metric |
| UOM | Each |
| id (mm) | 30 |
| Housing overall width | 37 |
| Weight (Kg) | 1.2405 |
| Seals | Seal and flinger on both sides |
| Features | Set screw locking |
| Bore Type | Cylindrical |
| Bearing Material | Bearing steel |
| Housing Material | Cast iron |
| Bearing/Insert reference | YAR 206-2F |
| Housing reference | TU 506 |
| Basic dynamic load rating | 19.5 kN |
| Basic static load rating | 11.2 kN |
| Limiting speed | 6300 r/min |
| EAN code | 07316570121117 |
Metric, Bearing unit, Cast iron, Set screw locking
