5 Metre, BS, Single strand roller chain, Steel (Standard), Industrial chain, Pitch, 0.625, EAN code: 07316572621066
| Brand | SKF |
|---|---|
| Mfr Part No. | C10B-1X5MTR |
| Acorn Code | C10B-1X5MTR-SKF |
| HS Code | 7315 89 00 00 |
| COO | China (CN) |
Chains are critical components in power transmission systems. Robust, quality chain drives extend mean time between failures, which reduces maintenance costs.
Straight side plate chains possess flat, rather than contoured, link plates for better sliding properties in conveyor applications. The fatigue strength and chain weight are slightly higher than for standard chains.
• Provide a strong chain
• Good sliding properties
• Easy to disassemble and replace
• Available as simplex, duplex and triplex
| Manufacturer Product Code | C10B-1X5MTR |
|---|---|
| Basic Product Description | Straight Side Plate Simplex Chain |
| Measurement | Imperial |
| UOM/Boxed Length | 5 Metre |
| Pitch (mm) | 15.875 |
| Width between inner plates b1 min (mm) | 9.65 |
| Roller diameter d1 max (mm) | 10.16 |
| Pitch (in) | 5/8 |
| Weight (Kg) | 4.7 |
| Strands | Single strand roller chain |
| Standard | BS |
| Range | Standard Series |
| Material | Steel (Standard) |
| EAN | 07316572621066 |
