SM 12 E-SS, SKF, Enhanced Vibracon SM 12 Stainless Steel

SKF Vibracon chocks are machinery mounting chocks that are easily and accurately adjusted, suitable for applications with a limited chock height. The chocks accommodate the angular difference between machine and the mounting base without expensive machining of the base or extra work of installing epoxy resin chocks. The self leveling capability combined with the height adjustment feature eliminates the possibility of a soft foot in the machine train through the life cycle of the machinery. Many installations where the SKF Vibracon chocks are applied can be found in tough, humid and salty climates, where protection against corrosion is recommended. To cater for this need, SKF has been testing different solutions resulting in the surface treated SKF Vibracon chock. All parts are treated individually to guarantee an optimal result, consistent quality and extended corrosion protecting capabilities.

• Suitable for M16 - M20 bolts (5/8" - 3/4")
• Eliminates soft foot
• Specially designed for limited chock heights
• Surface treatment against corrosion
• Highest possible safety for your installation
• Easy installation without prior knowledge
• Proven solution for many applications in a variety of industries

Specification
