Metric, Bearing, EAN code: 07316577449603
| Brand | SKF |
|---|---|
| Mfr Part No. | 32240/DF |
| Acorn Code | 32240/DF-SKF |
| HS Code | 8482 20 00 00 |
| COO | XXX |
Matched tapered roller bearings arranged face-to-face (X-arrangement, load lines diverge towards the bearing axis) accommodate high radial loads and axial loads in both directions. The precision manufactured intermediate ring between the outer rings enables a defined internal clearance or preload to be achieved when mounted. Matched tapered roller bearings are typically used in gearboxes, hoisting equipment, rolling mills, and machines in the mining industry.
| Manufacturer Product Code | 32240/DF |
|---|---|
| Basic Product Description | Matched tapered roller bearings arranged face-to-face |
| Measurement | Metric |
| id (mm) | 200 |
| od (mm) | 360 |
| Width (mm) | 208 |
| Weight (Kg) | 90.7 |
| Bore Type | Cylindrical |
| Matched arrangement | Face-to-face (X) |
| Cage material | Steel cage |
| Basic dynamic load rating | 2,229 kN |
| Basic static load rating | 4 |
| Limiting speed | 1 |
| Reference speed | 1 |
| EAN code | 07316577449603 |
Metric, Bearing, EAN code: 0053893374048
This item is not currently available from our stocks.
Despatch date information is on request.
