GE 60 TXE-2LS, SKF, Radial spherical plain bearing, maintenance-free, PTFE composite, sealed
Metric, Steel/PTFE, Seal on both sides, Maintenance-free, EAN code: 07316571875507
$105.70
In stock
Metric, Steel/PTFE, Seal on both sides, Maintenance-free
| Brand | IKO |
|---|---|
| Mfr Part No. | GE 60 EC-2RS |
| Acorn Code | GE60EC-2RS-IKO |
| HS Code | 8482 99 00 90 |
| COO | Japan (JP) |
These bushings have the same boundary dimensions as the GE...ES type and can be used internationally. A special PTFE liner reinforced with copper alloy meshes is used on the sliding surface. Therefore, creep deformation due to compressive loads is small, and wear resistance is superior. These bushings are used as maintenance-free bushings.
| ManufacturerProductCode | GE 60 EC-2RS |
|---|---|
| Basic Product Description | Radial spherical plain bearing, maintenance-free, PTFE composite, sealed |
| Measurement | Metric |
| UOM | Each |
| id (mm) | 60 |
| od (mm) | 90 |
| Width (mm) | 44 |
| Weight (Kg) | 1.1 |
| Lubrication | Maintenance-free |
| Seals | Seal on both sides |
| Relubrication feature | Without |
| Sliding material, contacting surfaces | Steel/PTFE |
| Material, inner ring | Bearing steel |
| Material, outer ring | Bearing steel |
| Basic dynamic load rating | 282 kN |
| Basic static load rating | 706 kN |
Metric, Steel/PTFE, Seal on both sides, Maintenance-free, EAN code: 07316571875507
Metric, Steel/PTFE, Seal on both sides, Maintenance-free
Metric, Steel/ELGOGLIDE, Seal on both sides, Maintenance-free, EAN code: 4012802532098
This item is not currently available from our stocks.
Despatch date information is on request.
